CALA 140-160H

CALA 140-160H

Kallaminator och monteringsmaskin med hjälpvärme i ovanvals. CALA140-160 kalllaminator för laminering, montering, applicering av tejp.

CALA 110H

Working width (mm) 1080
Paper input width 1120
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 20
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 1,25
Demensions 1400x1200x600
Weight (kg) 150

CALA 140H

Working width (mm) 1400
Paper input width 1420
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 20
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 1,7
Demensions 1750x1200x600
Weight (kg) 180

CALA 160H

Working width (mm) 1600
Paper input width 1620
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 30
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 2,7
Demensions 2000x1250x700
Weight (kg) 280

Mounting, hot and cold laminator

Improved version of CALA110 wide cold laminator for laminating, mounting, application tape and adhesive fixing equipped with a user friendly digital control panel for managing speed and temperature of the upper heater roller (up ro 60°C) in order to get a perfect result depending on the support to be precessed or the laminating material to be used.

CALA 110H

Working width (mm) 1080
Paper input width 1120
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 20
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 1,25
Demensions 1400x1200x600
Weight (kg) 150

CALA 140H

Working width (mm) 1400
Paper input width 1420
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 20
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 1,7
Demensions 1750x1200x600
Weight (kg) 180

CALA 160H

Working width (mm) 1600
Paper input width 1620
Upper roller temperature (°C) 60
Lower shaft for double-side adhesive tape included •
Manual rollers opening for panel mounting (mm) up to 30
Speed (m/min) up to 3
Additional shaft with roll support •
Electric pedal control •
Power requirements (V – Hz) 230 – 50/60
Power consumption (kW) 2,7
Demensions 2000x1250x700
Weight (kg) 280
