VINYL CUTTER C IV SERIES

Secabo‘s C IV series vinyl cutters are a consistent further development of the popular C III vinyl cutter series. Thanks to the improved cutting quality, increased reliability and a higher level of accuracy, it can be used in almost all pro-fessional areas of the sign-making industry. All common materials, such as adhesive films, self-adhesive films, flock and flex films, stencil films, paper, cardboard, etc. can be processed. The large backlit display and large buttons allow for easy operation of the vinyl cutter, while the improved LAPOS technology allows for precise cutting of the printed films. The vinyl cutters are comfortably controlled using the cutting software DrawCut LITE included in the delivery. A stable stand with a roll mount is optionally available for C60 IV and included with the C120 IV.

Click to download the Product Sheet

Kategori: Tagg:
DrawCut LITE cutting software
– standard on board!

The multilingual cutting software DrawCut LITE for Windows is included in the scope of delivery. DrawCut LITE not only reliably handles design and layout tasks and imports a wealth of graphic file formats, but also steers the Print&Cut applications of LAPOS 2, DrawCut LITE has many powerful text tools, vector functions, plotting and weeding tools and is therefore the ideal cutting software for quickly achieving professional plotting results with little training.

Stable stand with roll holder
– because order is essential

A stable stand is also included (except C30IV and C60IV). The roll holder makes working particu-larly fun: film rolls are unwound smoothly and jolt-free, thus ensuring high precision even with long plots.

Upgrade to DrawCut PRO available

You can upgrade from the supplied version of the DrawCut LITE cutting software to PRO at any time. DrawCut PRO‘s advanced design and layout tools will make your work easier and faster, while the vectorisation function will open new doors for you.More information at www.draw-cut.com.

KEY FEATURES :

● Mac compatible
● USB Interface
● 64 bit compatible
● Plug & play
● LAPOS
● DrawCut LITE Cutting software

Technical Data C30IV:

Max. Media width 420mm
Max. Cutting width 330mm
Max. Media thickness 1mm
Min. Media width 50mm
Repetition accuracy< ± 0.1mm
Repetition accuracy600mm/s
Max. Contact pressure 500g
Mechanical resolution 0.025mm
Environment +5°C – +35°C / 30% – 70% relative humidity
Connections serial, USB
Weight without packaging 9kg
Contour cut functionLAPOS, 4 crop marks
Items included Knife holder, drag knife, DIN A4 plot surface,
plot pen, connection cable, software, user manual

Technical Data C60IV:

Max. Media width 630mm
Max. Cutting width 720mm
Max. Media thickness 1mm
Min. Media width 50mm
Repetition accuracy< ± 0.1mm
Repetition accuracy600mm/s
Max. Contact pressure 500g
Mechanical resolution 0.025mm
Environment +5°C – +35°C / 30% – 70% relative humidity
Connections serial, USB
Weight without packaging 12kg
Contour cut functionLAPOS, 4 crop marks
Items included Knife holder, drag knife, DIN A4 plot surface,
plot pen, connection cable, software, user manual

Technical Data C120IV

Max. Media width 1260mm
Max. Cutting width 1350mm
Max. Media thickness 1mm
Min. Media width 50mm
Repetition accuracy< ± 0.1mm
Repetition accuracy600mm/s
Max. Contact pressure 500g
Mechanical resolution 0.025mm
Environment +5°C – +35°C / 30% – 70% relative humidity
Connections serial, USB
Weight without packaging 25kg
Contour cut functionLAPOS, 4 crop marks
Items included Knife holder, drag knife, DIN A4 plot surface,
plot pen, connection cable, software, user manual
