ECLIPS

ECLIPSE LABEL MINI+ – DIGITAL LABEL FINISHING MACHINE

Building on the success of the Eclipse MINI, the new (plus) model offers enhanced 220mm (8.6”) width media handling, in the same ultra-compact small footprint design.

Eclipse MINI+ is designed to work in combination with a wide range of leading ultra-narrow web label printers.

This new machine offers superb value for money. It is a competitively priced power-house machine, designed to harmonise and increase the flexibility of your label production.

Kategori: Tagg:

ACCURATE, FAST, ECONOMICAL!

The MINI+ digital die cutter and laminator is designed, engineered and built to the specification the printing community demand. Bringing affordable label finishing options to the micro label users of today. A small footprint innovation packed label finishing machine designed especially for the small producer needing flexibility of different shaped labels.

The Eclipse MINI+ comes with all the specifications you would expect to see in a larger sized industrial finishing equipment.

Specifications:

CUT WIDTH: 220mm (8.6”)
MEDIA WIDTH: 230mm (9”)
CUT SPEED: 800mm (1200”) Axial
LINEAR CUT SPEED: Dependent on graphic
CUT FORCE: 0 – 400 grams in 1 gram steps
CUT TYPE: Drag knife and tangential emulation
CUT to REGISTRATION: Single point
registration mark
CUT ABILITY: Both printed and unprinted media
MAX LABEL LENGTH: 254mm (10”) repeat
LAMINATION: Unsupported laminate roll
MAXIMUM ROLL DIAMETER: 200mm (7.9”)
WASTE MATRIX: Removal and rewind
ROLL SLITTING: 3 blade slitting and re-wind
ROLL CORE SIZE: 76mm (3”)
INTERFACE & SOFTWARE: WinPlot (Windows 0S)
cut software, cutter control parameter software.
Plug-ins for CorelDraw and Adobe Illustrator
POWER SUPPLY: Single phase 110/240VAC,
frequency 50/60HZ
DIMENSIONS: Width: 860mm (33.8”)
Depth: 520mm (20.5”) Height 575mm (22.6”)
WEIGHT: 75kg
