PLASTI 540 ASP

PLASTI 540 ASP är topplaminatorn i MAMO-sortimentet. Helautomatisk laminator med KBA sugmatningshuvud och BECKER vakuumpump. Extremt pålitliga med elektriska SCHNEIDER, OMRON-komponenter med användarvänlig programvara installerad på en pekskärmsenhet. Oljeuppvärmningssystem och pneumatiskt tryck ger en stabil temperatur och högt tryck för ett perfekt lamineringsresultat.

Click to download the Product Sheet

Kategori: Taggar: ,
PROFESSIONAL AUTOMATIC ROLL LAMINATOR FOR SINGLE SIDE LAMINATIONINDUCTION HEATING

PLASTI 540 ASP is top end laminating machine in MAMO range. Fully automatic laminator with BECKER vacuum pump. Extremely reliable user friendly software installed on a touch screen device. Induction heating system and pneumatic pressure grants fast reaching of target temperature and a stable heating during the process as well as high pressure for a perfect lamination result on any kind of printed material even at the maximum speed of 30mt per minute. Air expansion shaft releases film roll, and positions film roll more accurately, and also makes the loading and unloading of film roll easier. After automatic overlap and pneumatic cutting system that realizes laminated sheets separation sending themdirectly to the vibrating jogger (or on the optional stacker) for faster and more efficient trimming operations. Air compressor not included.



Technical Specifications:

Max Paper Size: 540×780mm
Min Paper Size: 290×290mm
Paper Thickness: 100-500gsm
Working Speed: 30m/min
Gross Power: 15 kW
Overall Dimensions: 3300×1250×1600mm
Weight: l000kgs
