Secabo TPD7

Secabo TPD7 pneumatic double-plate heat press



Kategori: Taggar: ,

Overview: Secabo TPD7 pneumatic double-plate heat press

The new TPD7 heat press by Secabo is ideal for professional and accurate processing of large-scale and extensive transfers in large editions and supports all commonly used transfer methods. The pressure produced by this double plate heat press is achieved through compressed air, which means significantly easier working and consistent, reproducible results. With a size 40 x 50 cm each, the two work plates offer a particularly generous working area for comfortable positioning of transfer objects. Unlike its predecessor, the TPD7’s base plates are provided in portrait format, further simplifying precise positioning of the objects to be transferred. The comfortable work surface on each exposed base plate also help increase the quality and precision of transfers. The horizontally movable heating plate head can be smoothly aligned over the respective work plate and the vertically impinging pressure allows for a flawless transfer of various materials without misalignments or similar issues. Quick change systems and replacable plates (only with the quick changer) for the new TPD7 are sold separately.

Features

Digital controller

Digital controller

Duration and temperature can easily be adjusted and monitored using the digital controller.

Variable work pressure

Variable work pressure

The work pressure is easy to adjust – in each case matching the transfer object and procedure.

Replaceable plates

Replaceable plates

Interchangeable base plates available – also in combination with a quick-change system

Safe working

Safe working

The safety and quality of this device is constantly monitored – according to German safety standards.

Precise temperature distribution

Precise temperature distribution

The high-quality heat plate ensures an exact temperature distribution over the entire heating surface.

Low hysteresis

Low hysteresis

A state-of-the-art controller reduces the temperature fluctuations to a minimum, thus ensuring consistently good transfer results.

Two work plates

Two work plates

with the 2 base plates, high production volumes can easily be achieved

Opens automatically

Opens automatically

The heat press automatically opens after the set time has elapsed.

Technical Data

dimensions100cm x 58cm x 75cm
working area2 x 40cm x 50cm
scope of deliveryheat press, power cord, compressor valve, manual
pressure settingsetting of pneumatic pressure
max. downforce350 g/cm²
max temperature225 °C
maximum time preset999 s
power supplyAC 230V / 50Hz – 60Hz, 1.8kW
environment+5°C – +35°C / 30% – 70% relative humidity
weight without packaging88,00 kg
weight with package115,88 kg
BrandSecabo
KEY FEATURES :

● Simple menu navigation
● Mac compatible
● USB Interface
● 64 bit compatible
● Plug & play
● Improved LAPOS
● DrawCut LITE

Technical Data C60 V:

Max. Media width 720mm
Max. Cutting width 630mm
Max. Media thickness 1mm
Max. cutting speed 600mm/s
Contact pressure 50 – 500g
Mechanical resolution 0.0245mm
Connections USB
Contour cut function LAPOS, 4 crop marks
Operation Backlit graphic LCD, gel buttons
Weight without packaging 12kg
Weight with packaging and stand 22kg
Dimensions 92cm × 26cm × 26cm
Items included Vinyl cutter, multilingual cutting software
DrawCut LITE (Windows) or SignCut 1-year
license (Mac), drag knife, ball-bearing knife holder,
plot pen, DIN A3 plot surface, stand with roll mount,
connection cable

Technical Data C120 V:

Max. Media width 1350mm
Max. Cutting width 1260mm
Max. Media thickness 1mm
Max. cutting speed 600mm/s
Contact pressure 50 – 500g
Mechanical resolution 0.0245mm
Connections USB
Contour cut function LAPOS, 4 crop marks
Operation Backlit graphic LCD, gel buttons
Weight without packaging 22kg
Weight with packaging and stand 32kg
Dimensions 160cm × 26cm × 26cm
Items included Vinyl cutter, multilingual cutting software
DrawCut LITE (Windows) or SignCut 1-year
license (Mac), drag knife, ball-bearing knife holder,
plot pen, DIN A3 plot surface, stand with roll mount,
connection cable
